Shear Beam Weighing Module
Theaded load hole confirguration
Low profile
OIML C3 approval
Alloy steel, stainless steel
FEATURES:
●Capacity: 0.1-10t
●Theaded load hole confirguration
●Low profile
●OIML C3 approval
●Alloy steel, stainless steel
APPLICATION:
●Floor scale
●Tank weighing
|
Outline Dimension |
|||||||||||
|
Rated capacity(t) |
L |
L1 |
L2 |
L3 |
L4 |
H |
H1 |
W |
C1 |
C2 |
T |
|
0.1，0.15,0.2,0.3， 0.5,0.75，1,1.5,2，2.5 |
130 |
12.7 |
76.2 |
25.4 |
53.5 |
31.8 |
15.7 |
31.8 |
Φ13.5 |
Φ13 |
M12 |
|
3,5 |
171.5 |
19 |
95.3 |
38.1 |
72.5 |
38.1 |
26 |
38.1 |
Φ20 |
Φ20 |
M18x1.5 |
|
7.5,10 |
225.5 |
25.3 |
124 |
50.8 |
102 |
50.8 |
25.4 |
50.8 |
Φ27 |
Φ27 |
M24x2 |
SPECIFICATION
Rated capacity: 0.1-10t
Rated output:3.0±0.002mv/v(0.1-0.3t); 3.0±0.003mv/v(0.5-10t)
Combined error：±0.03% F.S(alloy steel)；±0.05% F.S(stainless steel)
Non-repeatability：±0.02% F.S
Non-linearity：±0.02% F.S
Hysteresis error：±0.02% F.S
Zero balance: ±1% F.S
Creep error(30minutes): ±0.02% F.S
Temperature effect on zero: ±0.02% F.S
Temperature effect on output: ±0.02% F.S
Compensated temperature range: -10 ~ +40℃
Operating temperature range: -30 ~ +70℃
Maximum safe overload；150% OF R.C
Ultimate safe overload；180% OF R.C
Recommended Excitation；10 ~ 12V DC
Maximum Excitation；15V DC
Environment protection: IP67(0.1-0.3t); IP68(0.5-10t)
Input impedance: 400±20Ω
Output impedance: 352±3Ω
Insulation resistance at 50V DC: ≥5000MΩ
Material: alloy steel, stainless steel
Cable length: 1.5m/3m(0.1-2.5t),4.2m(3-5t),5m(7.5-10t); diameter 6mm
