Dosing Indicator

Load cell excitation voltage: DC5V, driving capability: 6 pcs with 350Ω; 12 pcs with 700Ω
Transmission rate: E protocol 19200 bps
Analog input voltage: -1mV/V~3mV/V
Sensitivity: 1.5uV/d

Send Inquiry

Product Introduction

SPECIFICATION:

Power supply:	DC24V
Load cell excitation voltage:	DC5V, driving capability: 6 pcs with 350Ω; 12 pcs with 700Ω
Transmission rate:	E protocol 19200 bps
Analog input voltage:	-1mV/V~3mV/V
Sensitivity:	1.5uV/d
Internal resolution	270000@2mV/V
Segment rate display	20000
A/D :	100 times/s
Nonlinearity:	<0.01%FS
Load cell port:	pluggable terminal blocks
Serial output:	electrical isolation half duplex RS232/ RS485
Baud rate:	1200, 2400, 4800, 9600, 19200 one start bit,7/8 data bit, one stop bit, none\odd\even parity optional
Status indication	fast, slow, discharge, material 1 ~ 4, net weight, stable, zero
Keyboard:	4 membrane touch switch
Number I/O	R30.20, 12-way PhotoMOS output,4-way switch input R30.00, 4-way PhotoMOS output,1-way switch input
Operating temperature:	-10℃~ 40℃
Housing material:	front panel: stainless steel; housing: aluminum
Weight:	0.5kg
