Y505-A Dissolved Oxygen Sensor For Aquaculture
Yosemitech Y505-A dissolved oxygen sensor is designed specifically for aquaculture.It doesn't consume oxygen,has no flow requirement,and doesn't require electrolyte.Additionally it isn't affected by hydrogen sulfide interference and offers excellent accuracy and stability.The sensor also features a built-in temperature sensor for automatic temperature compensation and digital RS485 output for convenient integrated application.
Product introduction
Yosemitech Y505-A dissolved oxygen sensor is designed specifically for aquaculture.It doesn't consume oxygen,has no flow
requirement,and doesn't require electrolyte.Additionally it isn't affected by hydrogen sulfide interference and offers excellent
accuracy and stability.The sensor also features a built-in temperature sensor for automatic temperature compensation and digital RS485 output for convenient integrated application.
Product features
◇ Digital sensor,RS485 output,MODBUS protocol
◇ No electrolyte required,strong anti-interference,no frequent calibration
◇ Customized for the aquaculture marketing,with high cost performance
◇ With automatic cleaning brush to prevent biological attachment and longer maintenance cycle
◇ Built-in calibration parameters,accurately calibrated before delivery,ready for direct installation and use
Product specification
|
Name |
Dissolved Oxygen Sensor |
|
Model |
Y505-A |
|
Measurement principle Range |
Fluorescence method 0-20mg/L or 0-200%saturation |
|
Accuracy |
±3% |
|
Temperature range |
0-50℃ |
|
Max water depth |
30m |
|
Housing IP rating |
IP68 |
|
Sensor interface |
Supports RS-485,MODBUS protocol |
|
Power requirements Installation |
0.1W(suggested power supply:DC 9-24V,current>50mA) M22*1.5(optional accessories can be converted to NPT3/4 thread),immersive installation |
|
Sensor size |
φ22mm*152.7mm |
|
Cable length Calibration |
10m(default),customizable One point or two points calibration |
|
Sensor housing material |
316L/Titanium alloy |
