Single-ended Beam Load Cell



FEATURES:

●Capacity: 100kg to 2t

●OIML C3 Certificate

●Stainless steel, Alloy steel



APPLICATION:

●Truck Scales

●Platform Scales







Outline Dimension
Rated capacity	H
0.1~0.5t	15.9
0.75~1t	19.1
1.5~2t	25.4



SPECIFICATION:

Rated capacity: 100kg to 2ton

Rated output:2.0±0.002mv/v

Combined error：±0.03% F.S

Non-repeatability：±0.02% F.S

Non-linearity：±0.03% F.S

Hysteresis error：±0.03% F.S

Zero balance: ±1% F.S

Creep error(30minutes): ±0.02% F.S

Temperature effect on zero: ±0.02% F.S

Temperature effect on output: ±0.02% F.S

Compensated temperature range: -10 to +40℃

Operating temperature range: -30 to +70℃

Maximum safe overload；150% OF R.C；120% OF R.C（20t~25t）

Ultimate safe overload；250% OF R.C；200% OF R.C（20t~25t）

Recommended Excitation；10 to 12V DC

Maximum Excitation；15V DC

Environment protection: IP67

Input impedance: 400±20Ω

Output impedance: 352±3Ω

Insulation resistance at 50V DC: ≥5000MΩ

Material: nickel-plated alloy steel

Cable length: 3meter, diameter 5mm
